转换IC/转接芯片NCS8810：HDMI 转 LVDS Converter w/ Scaler带缩放
|
**型号**：NCS8810
**产品特点**：低功耗，抗干扰能力强
**输入**：HDMI
**输出**：LVDS
**封装**：QFN-56 (7mm x 7mm) package
**1【特征】** Features
**LVDS输出**：LVDS Output
Single/Dual-channel 6/8bit LVDS interface
400Mbps to 1Gbps per data pair
Built-in termination
Channel swap supported
**HDMI输入**：HDMI Input
HDMI 1.4a supported
RGB444/YCbCr444 supported
Pixel clock up to 320MHz
I2S audio supported
Support Hot-Plug Detect
Adaptive equalization
**缩放：**Scaler
Hi-Fidelity scaler w/ super-resolution engine
**参考时钟：**Reference Clock
Any freq. between 19MHz and 100MHz
Crystal or single-ended clock input Built-in
5000ppm SSC generato
**其它**：Misc
I2C for chip configuration
Built-in video test pattern
**功率**：Power
1.25V core supply
3.3V IO supply
Deep-sleep mode power <5mW
@1280*720*60Hz to 1280*800*60Hz
w/ scaling ~392mW
@1280*720*60Hz to 1024*600*60Hz
w/ scaling ~362mW
**封装**：Package
QFN-56 (7mm x 7mm) package
RoHS Compliant
