**转换IC/转接芯片NCS8823：TYPE-C to VGA**
**型号**：NCS8823
**产品特点**：低功耗，高性能 TYPE-C 转换
**输入**：TYPE-C
**输出**：VGA
**封装**：QFN-32 (4mm x 4mm) package
**1【特征】** Features
**VGA输出**：VGA Output
Up to 1920x1080@60Hz supported
Compliant with VESA VSIS v1r2
166MSPS throughput
R/G/B swappable
Load sensing
5V tolerance DDC I/Os
**TYPE-C输入**：TYPE-C Input
USB Type-C Cable and Connector
Specification Revision 1.3 compatible
USB Power Delivery Specification Rev3.0
compatible
DisplayPort Alt Mode on USB Type-C
Standard Version 1.0a compatible
Support 2 Main Link Lanes at either
1.62Gb/s or 2.7Gb/s link rate
Roles supported: DRP
**参考时钟**：Clock
Refless clock system
**其它**：Miscellaneous
Selectable I2C slave
Embedded microcontroller
**功率**：Power
5V power supply
Power consumption ~TBD
**封装**：Package
QFN-32 (4mm x 4mm) package
RoHS Compliant
