【NCS8806方案】转换IC/信号转换芯片：LVDS to VBO with Scaler
|
**型号**：NCS8806
**产品特点**：低功耗，缩放效果好
**输入**：LVDS
**输出**：VBO
**封装**：eLQFP128 (14mm x 14mm)
**方案说明**：FHD分辨率LVDS电视板通过NCS8806点VBO接口的4K屏
**1【特征】** **Features**
**VBO输出**： *V-By-One (VBO) Output*
4/8-lane VBO @ max 3Gbps per lane
Up to 4K@60Hz supported
Up to 6dB pre-emphasis
Lane and polarity swap supported
**LVDS输入**：LVDS Input
Dual-channel LVDS interface
Up to 1080p@60Hz supported
Built-in termination
Channel and polarity swap supported
**缩放**：Scaler
Hi-Fidelity scaler w/ super-resolution engine
Reference Clock
Any freq. between 19MHz and 100MHz
Crystal or single-ended clock input
**参考时钟**：Reference Clock
Any freq. between 19MHz and 100MHz
Crystal or single-ended clock input
Built-in 5000ppm SSC generator
**其它**：Misc
I2C for chip configuration
Built-in VBO handshake protocol
Built-in video test pattern
**功率**：Power
1.5V core supply
3.3V IO supply
Deep-sleep mode power <5mW
~1.1W @4K60Hz w/ scaling
**封装**：Package
eLQFP128 (14mm x 14mm) package
RoHS Compliant
