PRODUCT DESCRIPTION
MS8422N is a 24 bit, high performance asynchronous sample rate
converter. It integrates digital audio interface receiver. It supports
IEC60958, S/PDIF, EIAJ CP1201 and AES3 interface standards.Audio
data is input by audio interface receiver or three wire serial audio
ports, and output through two three wire serial audio output ports.
QFN32 光纤同轴音频输入151 1247 6010 莫先生

FEATURES
 SPI or I2C software mode and stand-alone hardware mode
 All serial audio ports support master or slave mode
 Time division multiplexing mode (TDM) MS8422 MS4344数字音频接口解决方案15112476010莫先生.png

MS8422 MS4344数字音频接口解决方案15112476010莫先生.png

 Four general purpose output ports (GPOs)
 +3.3V analog supply voltage (VA)
 +1.8V-5.0V digital interface voltage (VL)
 Complete EIAJ CP1201, IEC-60958, AES3, S/PDIF compatible
 28 kHz to 216 kHz sample rate range
 2: 1 differential AES3 or 4:1 s / PDIF input multiplexer
 Low jitter clock recovery
 No external PLL filter is required
 Selectable and automatic clock switching
 On-chip channel state data buffer
 Automatic detection of compressed input audio data stream
 Decodes CD Q Sub-Code
 140 dB dynamic range
 -120 dB THD+N
