Vivado

2012年3月1日全新升级LP_wizard V10.4 ,自动生成器件封装

关键词:MENTOR, wizard, 收购, 破解

截图就不更新了。10.4版本,9个附件。
System Requirements
Microsoft .NET Framework Version 3.5
LP Wizard requires Mircosoft .NET Framework Version 3.5 to function. You must install Microsoft .NET Framework 3.5 before or after installing the LP Wizard software. Later versions of Mircrosoft .NET Framework (v4.0) are not compatible.
Problems Fixed in This Release
This section describes problems fixed for the LP Wizard 10.4 release.
dts0100804005
Assy Ref Des Height Min is always used by the 'Mounting Hole Calculator'
dts0100830198
LPWizard deletes user settings from Preferences.
dts0100830620
On invocation of LP Wizard, multiple license notes appear.
dts0100833529
SON Calculator rotating pins when it should not be
dts0100834959
Bad output for PADS from Side Flat/Concave Oscillator.
dts0100835136
Creating a new BGA pattern with a square pin pattern (e.g. count of 8 x 8) loses pins.
dts0100839744
LP Wizard output to PADS with Associated copper doesn't define copper shapes correctly
dts0100850081
LPW 10.4 - If invoked from Desktop a Logfile directory is created on Desktop - PADS 9.4 Beta 4
dts0100837870 Add an Oscillator "body style" option for "Flat" corners
dts0100837868 Need wildcard "*" search capability in LP Wizard libraries for Library >
Editor > Find













不知道LP Wizard是啥的,看下边两个帖子

http://www.eechina.com/thread-5719-1-1.html

http://www.eechina.com/thread-979-1-1.html

下载:

LPWizard_ESDM.ix2k.part01.rar (10 MB)
LPWizard_ESDM.ix2k.part02.rar (10 MB)
LPWizard_ESDM.ix2k.part03.rar (10 MB)
LPWizard_ESDM.ix2k.part04.rar (10 MB)
LPWizard_ESDM.ix2k.part05.rar (10 MB)
LPWizard_ESDM.ix2k.part06.rar (10 MB)
LPWizard_ESDM.ix2k.part07.rar (10 MB)
LPWizard_ESDM.ix2k.part08.rar (10 MB)
LPWizard_ESDM.ix2k.part09.rar (6.22 MB)




破解下载地址: http://www.eechina.com/thread-54544-1-1.html

1.先装软件,安装到默认路径,不安装license。
2.拷贝MentorKg.exe到C盘根目录
3.打开命令窗口。开始->运行-> CMD ->回车
4.输入命令 CD \    回车
5.输入命令 MentorKG -patch C:\MentorGraphics\10.3.2LPW 注意patch 为小写
6.稍等,会弹出一个TXT文档,将该文档另存为到 C:\LICENSE.TXT
7.右键我的电脑->属性->高级->环境变量 在 系统变量 中创建变量 MGLS_LICENSE_FILE , 变量值为 C:\LICENSE.TXT    若已经存在该变量,则修改变量值,在已有变量值后增加 ; 然后再增加C:\LICENSE.TXT
